PRODUCT PARAMETER
| Version |
Double-side |
| Power |
100W |
200W |
300W |
400W |
| Solar Panel Power |
6V 15W |
6V 25W |
6V 30W |
6V 40W |
| Solar Panel Size |
350*350*17mm |
530*350*17mm |
530*350*17mm |
700*350*17mm |
| Battery Capacity |
3.2V 15Ah |
3.2V 25Ah |
3.2V 32Ah |
3.2V 40Ah |
| Lamp Size |
375*180*70mm |
| LED Brand |
OSRAM |
| LED Type |
3030 |
| LED QTY |
100 pcs |
| CCT |
6500K |
| IP Rating |
IP65 |
| Material |
Aluminium |
| CRI |
>70 |
| Version |
Three-side |
| Power |
100W |
200W |
300W |
400W |
| Solar Panel Power |
6V 15W |
6V 25W |
6V 30W |
6V 40W |
| Solar Panel Size |
350*350*17mm |
530*350*17mm |
530*350*17mm |
700*350*17mm |
| Battery Capacity |
3.2V 15Ah |
3.2V 25Ah |
3.2V 32Ah |
3.2V 40Ah |
| Lamp Size |
375*220*70mm |
| LED Brand |
OSRAM |
| LED Type |
3030 |
| LED QTY |
150 pcs |
| CCT |
6500K |
| IP Rating |
IP65 |
| Material |
Aluminium |
| CRI |
>70 |
| Version |
Four-side |
| Power |
100W |
200W |
300W |
400W |
| Solar Panel Power |
6V 15W |
6V 25W |
6V 30W |
6V 40W |
| Solar Panel Size |
350*350*17mm |
530*350*17mm |
530*350*17mm |
700*350*17mm |
| Battery Capacity |
3.2V 15Ah |
3.2V 25Ah |
3.2V 32Ah |
3.2V 40Ah |
| Lamp Size |
375*295*70mm |
| LED Brand |
OSRAM |
| LED Type |
3030 |
| LED QTY |
200 pcs |
| CCT |
6500K |
| IP Rating |
IP65 |
| Material |
Aluminium |
| CRI |
>70 |
PRODUCT FEATURE
Integrated Sleeve Installation
This split solar street light uses an innovative integrated sleeve installation method, and the sleeve is inside the lamp body. The traditional sleeve with cover plate installation method often has a fracture problem at the interface, but this integrated sleeve installation method does not have this problem. It can more effectively resist strong winds in the sky and is more durable.
Patented Wide-angle Lighting
This split solar street light uses our HIGH CLASS patented wide-angle lighting technology, and the lighting angle can reach 270°. Its illuminated area can be wider than the single-wide lighting solar street light.
Brand New LiFePO4 Battery
When most of the solar street lights on the market use secondary recycled batteries, we insist on using brand-new lithium iron phosphate batteries to ensure the battery's stability and life, and the light can be turned on all night.
PRODUCT ADVANTAGE
Because this wide-angle lighting split solar street light uses HIGH CLASS patented wide-angle lighting technology, the lighting diameter of this split solar street light will be larger when installed at the same height. For example, when you have a road of 100m (328.08ft ) to be illuminated, you need 10 lights to cover the whole road with ordinary solar street lights, but you only need 6 lights to cover the whole road with this wide-angle lighting solar street light; in this way, you are equivalent to saving the cost of 4 solar street lights.
Now most solar street lights are installed using a cover plate to connect a small part of the arm, and then install the arm on the wall or light pole. After a long time, the connection port is easy to break, causing the light to fall off, forming a safety hazard. Our split solar street light uses an integrated sleeve installation method. The sleeve is embedded in the lamp housing, which means that most of the arm is inserted into the lamp housing. From a mechanical point of view, this installation method is stressed. The degree is better than the installation method in which only a small part is connected to the lamp housing, and it is challenging to break and cause safety accidents.
PRODUCT APPLICATION
